Ramping
MC4 User Guide 77
The following table presents the fields of the configuration window.
FIELD DESCRIPTION/OPTIONS
Range
(
*
The minimum and maximum value for the
ramping range.
Repeat Format
Wait in 0%
Rise Time
Wait in 100%
Fall Time
How the ramp should be carried out.
Use only full seconds, no decimals.
Repeats
Defines how many times all four phases
of the ramp are repeated. Value "zero"
equals continuous ramping.
*
)
Warning!
Do not configure the range settings so that they exceed the al-
lowed input range of the connected instrument. MC4
determines the limits of the range settings based on the
selected quantity and port, not the connected instrument.
Note.
MC4 actually makes the ramp in small steps. The steps are as small
as possible, slower ramps use smaller steps.
