Brunswick Sync - OPTIONAL BRUNSWICK A-2 PINSETTER MODIFICATIONS; New Pins Solenoid and Cycle Link

Sync Camera Assembly
9
OPTIONAL BRUNSWICK A-2 PINSETTER MODIFICATIONS
Centers that want proactive cycling for foul, no tap, and 3rd ball 10th frame situations, can purchase the
New Pins Solenoid kit. The kit incudes the following:
1. New Pins Solenoid
2. Cycle Link
3. Switch Cluster
4. Associated wiring and cables
New Pins Solenoid and Cycle Link
The New Pins Solenoid is used to switch the pinsetter to second ball in the event of a rst ball foul, third
ball, tenth frame or a No Tap strike to eliminate the bowler’s need to push the reset button. Refer to the
gure titled New Pins Solenoid.
NO NC COM
BLK
NC
3 2 1
J1
T1 T2
BLK
GRN
RED
8
NC
RED
GRN
WHT
BLK
2
10
1
9
SCANNER COM.
NPS (44/144) SW.
BLK
GRN
GRN
RED
0 SW.
5
7
6
3
4
12
11
14
15
13
T3
NC
BLK
RED
GRN
NC
NC
NC
NC
NC
NC
NC
NC
NC
(9)
PINSETTER
ELECTRICAL
BOX
(1)
TO
PERIPHERAL
CONTROLLER
(7)
TO
SWITCH
CLUSTER
(6)
RELAY
PCB
(3)
120 VAC
SOLENOID
BLK
WHT
BLK
GRN
RED
(5)
SOLENOID
LINK
(4) BRACKET
(6)
RELAY
PCB
(2)
SIGNAL
LED
T1
J1
T3
(3)
120 VAC
SOLENOID
(9)
PINSETTER
ELECTRICAL
BOX
(8)
NOT
USED
(7)
TO
SWITCH
CLUSTER
(1)
TO
PERIPHERAL
CONTROLLER
New Pins Solenoid
(1) TO PERIPHERAL CONTROLLER (2) SIGNAL LED (3) 120 VAC SOLENOID
(4) BRACKET (5) SOLENOID LINK (6) RELAY PCB
(7) TO SWITCH CLUSTER (8) NOT USED (9) PINSETTER ELECTRICAL BOX
