Sync Camera Assembly
39
3rd Ball 10th Frame
The following describes the events necessary for the third ball tenth frame scoring sequence.
This cycle occurs at the end of the tenth frame for a bowler that received a “bonus” ball after a spare or
a double. If the bowler does not strike on the “bonus” ball, the pinspotter will cycle a second time so
the next bowler is not required to push the Reset button to get a full rack, rst ball.
NOTE: The scorer console must be turned on, a bowler’s name entered, and the sequencing
arrows on a bowler’s name.
1. The bowler delivers the rst ball. The ball breaks the ball detect’s light path and sends a signal
to the Distribution Board.
2. The scoring process starts.
3. The pinsetter is triggered by the ball or if the pinsetter does not trigger on its own, the a reset
signal is sent from the Distribution Board to trigger the machine.
NOTE: If the pinsetter does not trigger on its own, the Distribution Board will automatically
take a picture and trigger the machine after a time delay that is calculated based on the fast ball/
slow ball settings as set on the scorer settings screen and continues from step 6.
4. The sweep falls downward causing the sweep switch to open - sending signal to the Distribution
Board.
5. After the time delay entered on the pinsettings screen at the control desk, the camera takes a
picture and sends it to the Distribution Board.
6. The picture is analyzed and it is determined a strike has not occurred.
7. The score is displayed.
8. The sweep switch closes to reset scoring cycle.
9. The Distribution Board sends a reset signal to the machine causing it to cycle a second time.
