Brunswick Sync - Mis-Scoring on Both Lanes (Non - GS Pinsetters)

Troubleshooting 9
Mis-Scoring on Both Lanes (Non - GS Pinsetters)
Has any
maintenance been
performed on the
pinsetters?
Start Here
Verify the pin
calibrations on the
Pin Setting screen
are correct
Check the Delay
and Level Settings
on the Pin Settings
screen
Check the ball
detectors
alignment and
mounting bracket.
Do the Ball
Detectors indicate
when the beam is
blocked?
Check the
Sweep/Rake
switch for
proper operation
Replace/Swap
the pin camera
Check the
Sweep/Rake
switch for
proper operation
Check for shiny
or oily spots on
the pin curtain
Check for
irregular bends
in the pin curtain
Check for
proper operation
of each pinsetter
YES
NO
NO YES
Check the ball
detector for
adjacent lanes
Replace ball
detector
Check the Fast ball/
Slow ball Trigg and
Speed limit settings
Verify the night
bowling setting is
set correctly
Replace
Peripheral
Controller
