12 System Overview
Sync Scorer System The Brunswick Sync scoring system consists of several pieces of equipment.
The main components in the scoring system include:
• Display Controllers
• Peripheral Controller Boxes
• Bowlers Consoles
Display Controller
Each Display Controller is capable of providing HD scoring video to the overhead monitors on a lane
pair.
Peripheral Controller
The Peripheral Controller handles multiple functions for a lane pair such as interfacing the pin camera,
controlling machine functions such as on/off and reset, and connecting signals needed for scoring such
as foul, sweep switch, and ball detector signals. It can control AMF short cycle and automated bumpers
as needed. It also provides power and communication to optional Vector keypads.
Bowler Consoles
The Sync bowler’s consoles can be equipped with standard membrane keypads, touchscreen keypads,
or full touchscreens capable of displaying the bowling scoresheet. Centers upgrading from Vector
scoring have the option of re-using their Vector keypads instead of Sync bowler’s consoles. Reference
the Sync Scoring System gures on the following pages.
