Brunswick Sync - No Scorer Video on Multiple Widescreen Monitors

Troubleshooting 17
No Scorer Video on Multiple Widescreen Monitors
Start Here
Reboot the
Display
Controllers
Verify the
monitor(s) are set
to the proper input
(HDMI)
Reboot the
24-port
Network Switch
Check the main
power panel for
tripped breakers
Are the
monitors'
power indicator
lights "On"?
NO
YES
Refer to the
overhead will not
turn on
troubleshooting
procedure.
Check the cat5 cables
and connections to the
24-port Network Switch
On the 24-port switch
at the overhead, is there
a Link and Activity light
illuminated for EACH
input that has a cable
attached to it?
YES
NO
Reboot the
24-port
Network Switch
Reboot the Vector
Network system
switch( es)
Power Cycle
the Display
Controllers
