Brunswick Sync - Receipt Printer

16 Sync Control System
Receipt Printer
POWER
ERROR
FEED
(6)
PUSH
TAB FORWARD
TO OPEN
COVER
(1)
POWER
SWITCH
(4)
CASH DRAWER
CONNECTOR
(5)
BACK VIEW OF RECEIPT
PRINTER
(2)
POWER CONNECTOR
(3)
SERIAL CONNECTOR
(7)
PAPER
WELL
(8)
VIEW WITH
COVER OPENED
Receipt Printer
(1) POWER SWITCH (2) POWER CONNECTOR (3) SERIAL CONNECTOR
(4) CASH DRAWER CONNECTOR (5) BACK VIEW OF RECEIPT PRINTER (6) PUSH TAB FORWARD TO
OPEN COVER
(7) PAPER WELL (8) VIEW WITH COVER OPENED
(1) Power Switch - This switch controls power to the printer.
(2) Power Connector - Input connector for main power.
(3) Serial Connector - Connection for serial cable from Sync Computer.
(4) Cash Drawer - Connection to the cash drawer.
