36
Sync Camera Assembly
SCORING SEQUENCE OF EVENTS
First Ball, Second Ball
The following describes the events necessary for the rst and second ball scoring sequences.
NOTE: The scorer console must be turned on, and a bowler’s name entered.
1. The bowler delivers the rst ball. The ball breaks the ball detect’s light path and sends a signal
to the Distribution Board.
2. The scoring process starts.
3. The pinsetter is triggered by the ball.
NOTE: If the pinsetter does not trigger on its own, the Distribution Board will automatically
take a picture and trigger the machine after a time delay that is calculated based on the fast ball/
slow ball settings as set on the scorer settings screen and continues from step 6.
4. The sweep falls downward causing the sweep switch to open - sending signal to the Distribution
Board.
5. After the time delay entered on the pinsettings screen at the control desk, the camera takes a
picture and sends it to the Distribution Board.
6. The picture is analyzed.
7. Score is displayed.
8. The sweep/rake switch closes to reset scoring cycle.
