Brunswick Sync - Pole Display;Receipt Printer; Cash Drawer

Sync Control System 15
POLE DISPLAY /RECEIPT PRINTER/ CASH DRAWER
The pole display, receipt printer, and cash drawer are connected to the Sync computer at a common
comport (usually Com2). Refer to gure titled POS Equipment Wiring Example
(1)
PC/HOST
(2)
DISPLAY
(3)
RS-232
PRINT
(4)
DC 12V
POWER IN
(8)
DB25
SERIAL CABLE
CONNECTOR
(6)
RECEIPT
PRINTER
(7)
POLE
DISPLAY
(5)
SERIAL PORT
COM 2
POLE DISPLAY
(9)
TO CASH DRAWER
POS Equipment Wiring Example
(1) PC/HOST (2) DISPLAY (3) RS-232 PRINT
(4) DC 12V POWER IN (5) SERIAL PORT COM2 POLE DISPLAY (6) RECEIPT PRINTER
(7) POLE DISPLAY (8) DB25 SERIAL CABLE CONNECTOR (9) TO CASH DRAWER
