Peripheral Controller Conguration Settings
Settings for the Peripheral Controller can be found in the Sync ofce program under the Lanes tab,
Distribution Board selection. These setting are congured at installation and typically do not need to
be altered when replacing the Peripheral Controller. They are provided here for reference purposes only.
Refer to gures titled Distribution Setup 1, Distribution Setup 2 and Distribution Properties.
1
2
Distribution Setup 1
Distribution Setup 2
