58 Sync Control System
Beep Speaker to Front Desk A/V (35’) Cable Assembly (Part No. 57-300500-000)
(1) TO J1 ON INTERCOM ASSEMBLY (2) BEEPER (3) DATA OUT
57-300184-000
(4) GROUND (5) CONTROL (6) DATA IN
(7) TO J3 ON BEEP SPEAKER
ASSEMBLY 57-300400-000
Ethernet Cable / CAT5e Cable (Part No. 57-500256-xxx)
(1) TO NETWORK DEVICE (2) TO ETHERNET SWITCH
