One or Both Widescreen Scorer Monitor(s) Will Not Turn On
Start Here
Check that
power is applied
to the back of
the monitor
YES
NO
YES
Use the OEM
remote control or
the power button on
the overhead to turn
on the monitor
Use the OEM
remote control
to select scorer
display input
Is video
displayed on
the monitor?
Is the monitor
set to off or
the wrong input at
the control
desk?
NO
Did the
monitor
power on?
Check the fuses
in the Brunswick
power supply box
Replace the
monitor
NO
Set the monitor
to scorer display
mode
YES
Verify the
monitor ID is
set to the proper
lane number
Verify the cables
and connection to
the monitor's
RS-232 connectors
Refer to the
scorer video
troubleshooting
procedure.
