FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
2
DESCRIPTION
ORIGINAL INSTRUCTIONS 43
2.8 Technical characteristics
2.8.1 Metal Detector
Special features THS/21E THS/21
Detection sensitivity High Very High
Immunity to environmental interference High High
Data display type
Alphanumeric OLED
4x20 characters
High-contrast graphical
OLED 128x64 pixels
Local programming
4 keys, 3
with double function
16 keys, 3
with double function
Control Power Box or Conveyor Control
System according to Standards UL 508A and
CSA-C22.2 No. 14-05
on request on request
Audio and visual detection indicators
Display of the signal level by means of bar graph
Inspected/contaminated product counter
ISO 9001 certified manufacturer
Extremely compact probe, on SL (Slim Line) version
Detector for magnetic and non-magnetic metals, for use with different types of product thanks to
selection of the operating frequency, on THS/MS21 and THS/21E-3F models
Detection of ferromagnetic metals when considerable quantities of aluminium or other non-magnetic
metals are present, on THS/MN21 model
Autolearn and automatic tracking of the product effect
Probe with circular opening for checking material transported in tubing, on THS/G21 models
Events storage Complete monitoring of occurred
events
Ejections
Test results
Programming accesses
Programming operations
Faults
Data management Management of electronic
production data and electronic
signatures as per CFR 21, Part
11
Data security
Data integrity
Data traceability
I/O interfaces RS232, Auxiliary RS232, Bluetooth, Ethernet/WiFi/USB (optional)
Signalling Acoustic Via internal buzzer
Optical Graphic display with bar-graph indication
Light indicators on control unit RED: Alarm or Fault
GREEN: Power on
Programming Local Built-in keyboard and high-contrast display
Remote through computer connected via Bluetooth, RS232, Ethernet or WiFi
and managed with CEIA MDScope software, THS Production
software or any other terminal emulation program
through Web Server, with optional IXC card
Inputs See table in section 2.2.6.1
Outputs
See table in section 2.2.6.1
Safety and Security Protection degree THS/21E IP65
THS/21 IP66 – IP69K
On UL versions, the Control Power Box and Conveyor Control
System have a 4X-12 certified degree of protection
Electrical insulation
Galvanic isolation of the mains voltage
Compliant with international standards for safety and radio
interference
Self-diagnosis
system
An internal self-diagnosis system continuously monitors Metal Detector functional efficiency. In the event
of a fault, a message is shown on the control display and all alarm indicators are activated together with
corresponding relays.
