FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
2
DESCRIPTION
ORIGINAL INSTRUCTIONS 35
2.6 Dimensions
2.6.1 Probes
2.6.1.1 THS/21, THS/MS21, THS/21E, THS/21E-3F
Series DW DH TH DL FHL TP FHP FHD DC TW
A 200, 250, ..., 1000 100, 125, 150,175 395 290 190 105
TP-30 DW+60
205 DW+420
B 350, 400, ..., 900 200, 225, 250, 275 550 390 290 160 280 DW+520
C 450, 500, ..., 1000 300, 325, 350 635 490 390 210 320 DW+620
Series DW DH TH DL FHL TP FHP FHD DC TW
D
500, 550, 600, 700,
800, 900, 1000,
1100, 1200, 1300
400, 450, 500 905 490 390 260 TP-30 DW+60 455 DW+720
