USE OF THE DEVICE
ORIGINAL INSTRUCTIONS 123
4.2.2 Conveyor Control System power supply unit control panel
On the power supply unit of the Conveyor Control System, the enclosure cover incorporates a
motor control panel.
Key Function
Start the conveyor belt *
Stop the conveyor belt
Increase speed
Programmable.
See the table below.
Manual forward
Decrease speed
Manual reverse
Metal Detector alarm reset
Can be disabled.
See Programming Manual
Emergency reset
The motor speed control keys, depending on UD and MM parameters, can have different functions:
MM
OFF ON
UD
OFF
No function Manual forward
No function Manual reverse
ON
Increase speed Manual forward
Decrease speed Manual reverse
Set MM=OFF on systems with THS/MBB, THS/M65, THS/MBR or on systems where the conveyor direction of travel
cannot be reversed.
The manual forward/reverse controls are only enabled when the belt is stopped.
The increase/decrease speed controls are enabled both when the belt is stopped and the belt is running.
