FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
4
USE OF THE DEVICE
ORIGINAL INSTRUCTIONS 137
TEST ABORTED
If the self-diagnosis system detects a
fault of any kind, the test procedure
will be interrupted and the message
shown here will be displayed.
In this case, the “REMOVE FAULT
CONDITIONS” message warns that
the test cannot be repeated without
first resetting the system.
THS/21E THS/21
=====================
TEST ABORTED
---------------------
FE
~
T
es
t
~-
0
.
80
~~
NO(1)
@
NFE Test-1.00
[\\\\\\\\\\\\\\\\\\\]
TEST ABORTED
{|||||||||||||||||||}
The test can also be interrupted by pressing P during the test.
In the event of an unsuccessful test, the message “TEST FAILED” is shown and the fault condition may be activated
according to the FF parameter (see Programming Manual).
The system can be set so that, after resetting, the test must be performed successfully (see the STM parameter in the
Programming Manual).
4.8.3 Quick test
You can run a single test without having to enter the programming mode. This is done by enabling
the input IN_AUX1 (for example with a pushbutton connected to it). Select the test by selecting the
QCKT parameter in the QA Configuration menu.
When you activate the input, the display will show a message requesting the corresponding test.
Run the test by passing the sample through the unit in the manual mode.
The result of the test will be recorded as usual in the event log as a Quick Test.
