FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
2
DESCRIPTION
ORIGINAL INSTRUCTIONS 45
2.8.2 Integrated systems
Special features Conveyor belt with integrated THS/21x Metal Detector and ejection system
HACCP compliant
Structure made from stainless steel and food-safe plastics as per FDA and USDA specifications
Conveyor belt (flat or modular) made from certified food-safe materials
System designed to the latest, most stringent safety standards
Conveyor Control System compliant with UL 508A and CSA-C22.2 No. 14-05 standards (on request)
High-reliability motor with stainless steel protective cover, high drive capacity version
Easy belt alignment
Digital speed adjustment
Quick and easy to clean
Easy maintenance and inspection
Ejection mode Belt stop, pneumatic pusher ejection, air jet ejection, deviator arm, belt reversing (only on THS/FBB and
THS/FB), belt retraction (THS/MBR)
Events storage Complete monitoring of occurred
events
Ejections
Test results
Programming accesses
Programming operations
Faults
Data management Management of electronic
production data and electronic
signatures as per CFR 21, Part
11
Data security
Data integrity
Data traceability
I/O interfaces RS232, Auxiliary RS232, Bluetooth, Ethernet/WiFi/USB (optional)
Signalling Acoustic Via external buzzer and internal buzzer
Optical Graphic display with bar-graph indication
Light indicators on control unit RED: Alarm or Fault
GREEN: Power on
External beacon RED: Alarm or Fault
AMBER: Alarm (optional)
BLUE: Test request (optional)
Programming Local Built-in keyboard and high-contrast display
Remote through computer connected via Bluetooth, RS232, Ethernet or WiFi
and managed with CEIA MDScope software, THS Production
software or any other terminal emulation program
through Web Server, with optional IXC card
Inputs
Conveyor Control System
Ejection confirmation, Photocell, Reset, Low pressure, Encoder, Bin
full, Emergency buttons, Barcode reader, Following Conveyor,
Inhibition, Bin absent, Ejector position check, Ejector check
Outputs
Conveyor Control System
Test request, Upstream conveyor, System ready, Ejection in
progress, Alarm, Ejector, External beacon
Safety and Security Protection degree Metal Detector THS/21E IP65
Metal Detector THS/21 IP66 – IP69K
THS/FB IP65
THS/FBB, THS/MBB,
THS/M65, THS/MBR
Motor IP55
Rest of the system IP65
THS/M69K IP66 – IP69K
On UL versions, the Conveyor Control System has a 4X-12 certified
degree of protection
Noise emissions
Noise level as per Directive
2006/42/EC
<70 dB(A); <130 dB(C)
Electrical insulation
Compliant with international standards for safety and radio
interference
Self-diagnosis
system
An internal self-diagnosis system continuously monitors Metal Detector functional efficiency. In the event
of a fault, a message is shown on the control display and all alarm indicators are activated together with
corresponding relays.
