FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
DESCRIPTION
30 ORIGINAL INSTRUCTIONS
2.3.2.5 THS/MBR (modular belt)
THS/MBR
A
Metal Detector antenna
B
Programming and control panel
C
Main switch
D
Conveyor belt control panel
E
Synchronization photocell
F
External beacon
G
Emergency button
H
Reject bin
L
Retracting section of the belt
M
Support feet (to be fixed to the floor)
Available features and options
Belt length 1700 2000
F Signalling
Red lamp for alarm and fault
 
Amber lamp for alarm and external
buzzer
 
Blue lamp for test request
 
E Synchronization photocell
 
- Belt variable speed
 
- Belt type
Flush grid
 
Flat top
 
- Belt height 875 mm
 
M Stand type Adjustable feet ±75 mm
 
H Reject bin Standard
 
- Side panels for product containment
 
- Sensors kit
Ejection confirmation, bin full alarm
 
Low pressure alarm
 

Standard

Accessory / Option

Not available
