FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
2
DESCRIPTION
ORIGINAL INSTRUCTIONS 25
2.3.1 Inverting component positions
2.3.1.1 Inverting the antenna/PSU unit position
It is possible, as an option at the order stage, to invert the position of the controls of the
antenna/PSU unit, moving the controls to the other side of the conveyor belt.
Antenna Front
Antenna Back
2.3.1.2 Inverting the ejection system position
It is also possible, as an option at the order stage, to invert the position of the ejection system as
shown in the figure below.
Ejection Back/Front
Ejection Front/Back
