FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
2
DESCRIPTION
ORIGINAL INSTRUCTIONS 17
2 DESCRIPTION
2.1 General description
CEIA THS inspection systems detect metals with high detection sensitivity, for industrial use in
inspecting food or other compatible products (see paragraph 2.1.3). They are available in two
versions:
- Detection antenna with power supply unit
- Detection antenna with integrated conveyor belt system
2.1.1 Detection probe
This system is designed for installation on a production line suitably set up by the customer or the
installer. It consists of a detection antenna and a power supply unit only.
Both the antenna and the power supply unit are available in different configurations. The antenna is
available in various configurations to match different detection requirements. The power supply unit
is available configured for the control of the Metal Detector only or for control of the conveyor belt
provided by the customer.
All models are available in two different subclasses, the 21E Series and the 21 Series, with
different features and characteristics, as stated below:
Features 21E Series 21 Series
Display type
Alphanumeric OLED
4x20 characters
Graphic OLED
128x64 pixels
Local Programming
4 keys
3 with double function
16 keys
3 with double function
Alphanumeric data entry No Yes
Quick Access function No Yes
Autotest function No Yes
Automatic detection
performance evaluation
No Yes
Sensitivity High Very High
Product memories 250 500
Event log 1000 10000
Detection technology 3F Technology Multi Spectrum Technology
Protection degree IP65 IP66 and IP69K
