FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
3
INSTALLATION
ORIGINAL INSTRUCTIONS 47
3 INSTALLATION
Before starting any installation operation, carefully read the Safety instructions – Warnings section of this manual.
Observe current regulations regarding electrical and personal safety for both the operator and the installer when installing
the device.
3.1 General requirements
The minimum installation requirements depend on the THS model being installed. For precise
details, see the Technical Specifications section.
3.1.1 Minimum clearances
3.1.1.1 Probes
For safe use of the equipment by the operator, provide at least 50 cm in front of the control panel
and the power supply unit, in its configuration with the door open.
3.1.1.2 Integrated systems
For safe use of the equipment by the operator, provide at least 50 cm around the equipment, in its
configuration with all the doors open and the reject bin absent.
Example for THS/FB and THS/MB Example for THS/FBB and THS/MBB
