FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
USE OF THE DEVICE
132 ORIGINAL INSTRUCTIONS
4.5.6.3 THS/MBR
Press the Stop Belt button
Using the key provided, release the
reject bin. Turn the handle to release it.
Remove the bin from its seat.
Empty the bin. At the end of the
operation, place the bin in the guides
and lock it again, with the handle or the
safety key.
After emptying, slide the bin onto its
guides. Lock it in position with the
handle and the key.
Check that all the safety devices are
present and efficient. Check for other
hazards. Start the belt by pressing
the Start button.
If the "Emergency activation if bin absent" option is installed, when the reject bin is removed, the
machine goes into Emergency status. After replacing the bin, to reset the system press the
Emergency Reset button R.
