FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
DESCRIPTION
20 ORIGINAL INSTRUCTIONS
2.2.3 THS/MN21
The THS/MN21 is a very-high sensitivity Metal Detector for detecting ferromagnetic metal
contaminants in products inside containers made from non-magnetic metal foil (e.g. aluminium foil)
or inside aluminium trays.
It is also used to detect needles in clothes with non-magnetic accessories (buttons, zips, etc. …).
THS/MN21
A
The Metal Detector probe complete with electronic control
unit
B
The Control Power Box, for connecting the device to mains
power and to the external units (photocell, ejector, etc.).
See section 2.3 for all possible configurations.
C
Connecting cable
D
Tunnel
E
Stainless steel control panel, fitted with graphic display and
16-key programming keyboard
F
Field generator
