Ceia THS/MS21 - THS;M65 and THS;M69 K; Ths;Mbb

FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
2
DESCRIPTION
ORIGINAL INSTRUCTIONS 41
2.6.3.3 THS/MBB
Model BL BW
BH
TW
castors
feet feet extension *
700 875 125 250
THS/MBB 1000, 1300, 1500, 1800
300
920 ±50 700 ±75 875 ±75 1000 ±75 1125 ±75
601 - 1226
450 651 - 1276
600 701 - 1326
* available only on belt height 875 mm
2.6.3.4 THS/M65 and THS/M69K
Model BL BW
BH
TW
castors
feet feet extension *
700 875 125 250
THS/M65 1300, 1500, 1800
300
not
available
700 ±75 875 ±75 1000 ±75 1125 ±75
750 - 1051
450 900 - 1201
600 1050 - 1351
* available only on belt height 875 mm
