Ceia THS/MS21 - Connections to Other Devices; 00211 ALM Card

3
FI002K0018v1100UK – THS/21 Instruction manual for installation, use and maintenance
INSTALLATION
92 ORIGINAL INSTRUCTIONS
3.7 Connections to other devices
3.7.1 00211ALM card
Connector Pin Label IN/OUT Type
Range/Max.
value
Function
J01
1
1 C
Output
Common
30 V AC/DC 2.5A
Auxiliary relay (not used)
2 NC N.C. contact
3 NO N.O. contact
4 C
Output
common
Test request
5 NC N.C. contact
6 NO N.O. contact
7 C
Output
common
Upstream conveyor relay
8 NC N.C. contact
9 NO N.O. contact
J02
1 C
Output
common
30 V AC/DC 2.5A
Ready relay
2 NC N.C. contact
3 NO N.O. contact
4 C
Output
common
Ejection relay
5 NC N.C. contact
6 NO N.O. contact
7 C
Output
common
Alarm relay
8 NC N.C. contact
9 NO N.O. contact
10 GND - ground -
J03
1 24 Vac
Input
24 Vac
24 V power supply input from AC/DC converter
2 +24 Vdc/ac +24 Vdc/ac
3 0 Vdc 0 Vdc
4 - - - -
Reserved
5 - - - -
J04
Only used with the inverter module
on Conveyor Control System
J05
Reserved
J06
Reserved
J07
1
1 - - - -
Reserved
2 - - - -
3 - - - -
4
]
Emergency reset input
Keep jumpered on Control Power Box
5
6 - - - -
Reserved
7 - - - -
J08
Reserved
1
Connector not present on Control Power Box – basic version
