Page #1201 background imageLoading...
Page #1201 background image
46-63
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 46 Configuring 802.1X Port-Based Authentication
Configuring 802.1X Port-Based Authentication
Note Removing a 802.1X MAB configuration from a port does not impact the authorized or authenticated
state of the port. If the port is in an unauthenticated state, it remains in that state. If the port is in an
authenticated state because of MAB, the switch reverts to the 802.1X Authenticator. If the port was
already authorized with a MAC address and the MAB configuration was removed, the port remains in
an authorized state until reauthentication occurs. At that time, if an 802.1X supplicant is detected on the
wire, the MAC address is removed.
This example shows how to enable MAB on Gigabit Ethernet interface 3/3 and to verify the
configuration:
Cisco IOS Release 12.2(50)SG and later
Switch# configure terminal
Switch(config)# interface gigabitethernet3/3
Switch(config-if)# switchport mode access
Switch(config-if)# dot1x pae authenticator
Switch(config-if)# authentication port-control auto
Switch(config-if)# mab
Switch(config-if)# end
Switch# show mab int g3/3 details
MAB details for GigabitEthernet3/3
-------------------------------------
Mac-Auth-Bypass = Enabled
MAB Client List
---------------
Client MAC = 0001.0001.0001
Session ID = C0A8016F0000002304175914
MAB SM state = TERMINATE
Auth Status = AUTHORIZED
Cisco IOS Release 12.2(46)SG or earlier
Switch# configure terminal
Switch(config)# interface gigabitethernet3/3
Switch(config-if)# switchport mode access
Switch(config-if)# dot1x pae authenticator
Switch(config-if)# dot1x port-control auto
Switch(config-if)# dot1x mac-auth-bypass
Switch(config-if)# end
Switch# show dot1x int g3/3 details
Dot1x Info for GigabitEthernet3/3
-----------------------------------
PAE = AUTHENTICATOR
PortControl = AUTO
ControlDirection = Both
HostMode = SINGLE_HOST
ReAuthentication = Disabled
Step 7
Switch(config)# end
Returns to privileged EXEC mode.
Step 8
Switch# show mab interface
interface-id details
(Optional) Verifies your entries.
Step 9
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose
