Cisco Catalyst 4500 Series Administration Guide

58-23
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 58 Configuring SPAN and RSPAN
Configuring RSPAN
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# no monitor session 2
Switch(config)# monitor session 2 source vlan 1 - 3 rx
Switch(config)# monitor session 2 destination remote vlan 902
Switch(config)# monitor session 2 source vlan 10 rx
Switch(config)# end
Specifying VLANs to Filter
To limit RSPAN source traffic to specific VLANs, perform this task:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# no monitor session
{session_number | all | local |
remote}
Clears any existing SPAN configuration for the session.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
Specify all to remove all SPAN sessions, local to remove all local
sessions, or remote to remove all remote SPAN sessions.
Step 3
Switch(config)# [no] monitor session
{session_number} {source {interface
interface_list | {vlan vlan_IDs | cpu
[queue queue_ids]} [rx | tx | both]
Specifies the characteristics of the source port (monitored port) and
RSPAN session.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
For interface-list, specifies the source port to monitor. The interface
specified must already be configured as a trunk port.
For vlan-IDs, the range is 1 to 4094; do not enter leading zeros.
For queue_ids, specifies the source queue.
(Optional) [, | -] Specifies a series or range of interfaces. Enter a space
after the comma; enter a space before and after the hyphen.
(Optional) Specifies the direction of traffic to monitor. If you do not
specify a traffic direction, the source interface sends both transmitted
(Tx) and received (Rx) traffic. Only received traffic can be monitored
on additional source ports.
• Rx—Monitor received traffic.
• Tx—Monitor transmitted traffic.
• both—Monitor both received and transmitted traffic
(bidirectional).
Step 4
Switch(config)# monitor session
session_number filter vlan vlan-id [,
| -]
Limits the RSPAN source traffic to specific VLANs.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
For vlan-id, the range is 1 to 4094; do not enter leading zeros.
(Optional) Use a comma (,) to specify a series of VLANs or use a
hyphen (-) to specify a range of VLANs. Enter a space after the
comma; enter a space before and after the hyphen.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
