Cisco Catalyst 4500 Series Administration Guide

58-22
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 58 Configuring SPAN and RSPAN
Configuring RSPAN
To remove one or more source VLANs from the RSPAN session, use the no monitor session
session_number source vlan vlan-id rx global configuration command.
This example shows how to clear any existing configuration on RSPAN session 2, configure RSPAN
session 2 to monitor received traffic on all ports belonging to VLANs 1 through 3, and send it to
destination remote VLAN 902. The configuration is then modified to also monitor received traffic on all
ports belonging to VLAN 10.
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# no monitor session
{session_number | all | local |
remote}
Clears any existing SPAN configuration for the session.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
Specify all to remove all SPAN sessions, local to remove all local
sessions, or remote to remove all remote SPAN sessions.
Step 3
Switch(config)# [no] monitor session
{session_number} {source {interface
interface_list | {vlan vlan_IDs | cpu
[queue queue_ids]} [rx | tx | both]
Specifies the RSPAN session and the source VLANs (monitored
VLANs). You can monitor only received (rx) traffic on VLANs.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
For interface-list, specifies the source port to no longer monitor. Valid
interfaces include physical interfaces and port-channel logical
interfaces (port-channel port-channel-number).
For vlan-IDs, the range is 1 to 4094; do not enter leading zeros.
For queue_ids, specifies the source queue.
(Optional) [, | -] Specifies a series or range of interfaces. Enter a space
after the comma; enter a space before and after the hyphen.
(Optional) Specifies the direction of traffic to monitor. If you do not
specify a traffic direction, the source interface sends both transmitted
(Tx) and received (Rx) traffic. Only received traffic can be monitored
on additional source ports.
• Rx—Monitor received traffic.
• Tx—Monitor transmitted traffic.
• both—Monitor both received and transmitted traffic
(bidirectional).
Step 4
Switch(config)# monitor session
session_number destination remote
vlan vlan-id
Specifies the RSPAN session, the destination remote VLAN.
For session_number, specifies the session number identified with this
RSPAN session (1 through 6).
For vlan-id, specifies the RSPAN VLAN to carry the monitored traffic
to the destination port.
Step 5
Switch(config)# end
Returns to privileged EXEC mode.
Step 6
Switch# show monitor [session
session_number]
Verifies your entries.
Step 7
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
