Managing a Network Using Cluster
Note If you have enabled clustering, you should disable clustering before configuring a community (see
Table 15-2).
Managing a Network Using Cluster
This section describes how to use clustering to create and manage Catalyst 4500 series switches using
the standalone Network Assistant application or the command-line interface (CLI).
Use clustering to group the switches in your network. You must enter the cluster run command on each
switch to be managed. The major advantage is that you can manage 16 devices with one IP address.
Note Clustering is the auto-discovering mechanism used in CNA 1.0.
Note For complete procedures for using Network Assistant to configure switch clusters, refer to
Getting Started with Cisco Network Assistant, available at:
http://www.cisco.com/en/US/products/ps5931/prod_installation_guides_list.html.
This section contains the following topics:
• Understanding Switch Clusters, page 15-11
• Using the CLI to Manage Switch Clusters, page 15-13
Understanding Switch Clusters
These sections describes these topics:
• Cluster Command Switch Requirements, page 15-11
• Network Assistant and VTY, page 15-12
• Candidate Switch and Cluster Member Switch Requirements, page 15-12
Cluster Command Switch Requirements
A cluster command switch must meet these requirements:
• Uses Cisco IOS Release 12.2(20)EWA or later.
• Has an IP address.
• Cisco Discovery Protocol (CDP) version 2 is enabled (the default).
• Uses cluster-capable software and has clustering enabled.
• IP HTTP (or HTTPS) server is enabled.
Note On a Catalyst 4500 series switch, neither HTTP or HTTPS is enabled by default.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
