Cisco Catalyst 4500 Series Administration Guide

54-15
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 54 Configuring Network Security with ACLs
Configuring EtherType Matching
This example shows how to create and display an access list named mac1, denying only EtherType
DECnet Phase IV traffic, but permitting all other types of traffic:
Switch(config)# mac access-list extended mac1
Switch(config-ext-macl)# deny any any decnet-iv (old) protocol-family decnet (new)
Switch(config-ext-macl)# permit any any
Switch(config-ext-macl)# end
Switch # show access-lists
Extended MAC access list mac1
deny any any decnet-iv (old) protocol-family decnet (new)
permit any any
The following example shows how to enable or disable hardware statistics while configuring ACEs in
the access list:
Switch# config t
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# mac access-list extended mac1
Switch(config-ext-nacl)# hardware statistics
Switch(config-ext-nacl)# end
Switch# show access-lists
Extended MAC access list macl
deny any any decnet-iv (old) protocol-family decnet (new)
permit any any
hardware statistics
Configuring EtherType Matching
You can classify non-IP traffic based on the EtherType value using the existing MAC access list
commands. When you classify non-IP traffic by EtherType, you can apply security ACLs and QoS
policies to traffic that carry the same EtherType.
EtherType matching allows you to classify tagged and untagged IP packets based on the EtherType
value. Tagged packets present a potential operation problem:
• While single-tagged packets are supported on the access and trunk ports, double-tagged packets are
not.
• Single and double-tagged packets are not supported if the port mode is dot1qtunnel.
For more information about the mac access-list extended command, refer to the Catalyst 4500 Series
Switch Cisco IOS Command Reference.
Step 5
Switch# show access-lists [number | name]
Shows the access list configuration.
Step 6
Switch(config)# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose
