Cisco Catalyst 4500 Series Administration Guide

15-2
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 15 Configuring the Catalyst 4500 Series Switch with Cisco Network Assistant
About Network Assistant
Note For information on software and hardware requirements, installing Network Assistant, launching
Network Assistant, and connecting Network Assistant to a device refer to Getting Started with Cisco
Network Assistant, available at the URL:
http://www.cisco.com/en/US/products/ps5931/prod_installation_guides_list.html.
About Network Assistant
Network Assistant is a free network management tool that allows you to configure and manage Catalyst
4500 series switches using a graphical user interface (GUI). Network Assistant works in both secure and
unsecure environments. Network Assistant manages standalone devices or groups of devices or switches
(in communities or clusters) from anywhere in your intranet. Using Network Assistant, you can perform
multiple configuration tasks without having to remember commands.
Community Overview
A community is a device group that can contain up to 20 connected network devices. Network Assistant
uses the Cisco Discovery Protocol (CDP) automatic discovery capability to find eligible network devices
and to add them to a community. When a network device is added to a community, it becomes a member
device. Network Assistant manages, configures, and monitors each member on an individual basis;
therefore, each member must have an IP address assigned to it.
When you use communities, you need to have an HTTP server, and you need to configure an IP address
on each switch.
Clustering Overview
A switch cluster is a set of up to 16 connected, cluster-capable Catalyst switches that are managed as a
single entity. The switches in the cluster use the switch clustering technology so that you can configure
and troubleshoot a group of different Catalyst 4500 series switch platforms through a single IP address.
Using switch clusters simplifies the management of multiple switches, regardless of their physical
location and platform families.
Note By default, Network Assistant in clustering mode discovers up to seven hops away.
In a switch cluster, one switch must be the cluster commander switch, and up to 15 other switches can
be cluster member switches. The total number of switches in a cluster cannot exceed 16 switches. The
cluster command switch is the single point of access used to configure, manage, and monitor the cluster
member switches. Cluster members can belong to only one cluster at a time.
Note Always choose a Catalyst 4500 or 4948 series switch as the cluster command switch.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
