Page #1206 background imageLoading...
Page #1206 background image
46-68
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 46 Configuring 802.1X Port-Based Authentication
Configuring 802.1X Port-Based Authentication
SuppTimeout = 30
ReAuthPeriod = 3600 (Locally configured)
ReAuthMax = 2
MaxReq = 2
TxPeriod = 30
RateLimitPeriod = 0
Critical-Auth = Enabled
Critical Recovery Action = Reinitialize
Critical-Auth VLAN = 17
Dot1x Authenticator Client List
-------------------------------
Supplicant = 0000.0000.0001
Auth SM State = AUTHENTICATING
Auth BEND SM Stat = RESPONSE
Port Status = AUTHORIZED
Authentication Method = Dot1x
Authorized By = Critical-Auth
Operational HostMode = SINGLE_HOST
Vlan Policy = 17
Switch#
Configuring 802.1X with Unidirectional Controlled Port
To configure unidirectional controlled port, perform this task:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# interface
interface-id
Specifies the port to be configured and enters interface configuration
mode.
Step 3
Switch(config-if)# switchport mode
access
or
Switch(config-if)# switchport mode
private-vlan host
Specifies a nontrunking, nontagged single VLAN Layer 2 interface.
Specifies that the ports with a valid PVLAN trunk association become active
host PVLAN trunk ports.
Step 4
Switch(config-if)# dot1x pae
authenticator
Enables 802.1X authentication on the port with default parameters.
Refer to the “Default 802.1X Configuration” section on page 46-30.
Step 5
Switch(config-if)# authentication
port-control auto
Enables 802.1X authentication on the interface.
Step 6
Cisco IOS Release 12.2(50)SG and later
Switch(config-if)# authentication
control-direction {in | both}
Cisco IOS Release 12.2(46)SG or earlier
releases
Switch(config-if)# dot1x
control-direction {in | both}
Enables unidirectional port control on each port.
Step 7
Switch(config)# end
Returns to privileged EXEC mode.
Step 8
Switch# show dot1x interface
interface-id details
(Optional) Verifies your entries.
Step 9
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
