Cisco Catalyst 4500 Series Administration Guide

40-11
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 40 Configuring Policy-Based Routing
Policy-Based Routing Configuration Tasks
Enabling Local IPv4 and Local IPv6 PBR
Packets that are generated by the switch are not normally policy-routed. To enable local PBR for such
packets, indicate which route map the switch should use by entering this command:
IPv4
IPv6
All packets originating on the switch are then subject to local PBR.
Use the show ip local policy command to display the route map used for local PBR, if one exists.
Examples of the show Command
The following show command illustrates that route map pbrv6-test has only one permit sequence.
In the example policy, IPv6 packets with an address matching the criteria defined by the access control
list v6_acl are forwarded to the next hop 2006::2. If next-hop 2006::2 is unreachable, the matching
packets are forwarded to 2005::2. If both next-hops are unreachable, the packets are forwarded using the
routing table lookup. For packets that do not match the filter criteria, a standard routing table lookup is
performed for packet forwarding.
Switch# show route-map pbrv6-test
route-map pbrv6-test, permit, sequence 10
Match clauses:
ipv6 address v6_acl
Set clauses:
ipv6 next-hop 2006::2 2005::2
Policy routing matches: 0 packets, 0 bytes
Unsupported Commands
The following PBR commands in config-route-map mode are in the CLI but not supported in Cisco IOS
for the Catalyst 4500 series switches. If you attempt to use these commands, an error message displays:
• match-length
• set ip qos and set ipv6 qos
• set ip tos and set ipv6 tos
• set ip precedence and set ipv6 precedence
• set ip df and set ipv6 df
Command Purpose
Switch(config)# ip local policy route-map map-tag
Identifies the IPv4 route map to use for local PBR.
Command Purpose
Switch(config)# ipv6 local policy route-map map-tag
Identifies the IPv6 route map to use for local PBR.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
