Cisco Catalyst 4500 Series Administration Guide

8-22
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL-30933-01
Chapter 8 Configuring Interfaces
Configuring Optional Interface Features
To restore autonegotiation, enter the no speed nonegotiate command in the interface configuration
mode.
Note For the blocking ports on the WS-X4416 module, do not set the speed to autonegotiate.
Setting the Interface Duplex Mode
Note When the interface is set to 1000 Mbps, you cannot change the duplex mode from full duplex to half
duplex.
To set the duplex mode of a Fast Ethernet interface, perform this task:
This example shows how to set the interface duplex mode to full on Fast Ethernet interface 5/4:
Switch(config)# interface fastethernet 5/4
Switch(config-if)# duplex full
Displaying the Interface Speed and Duplex Mode Configuration
To display the interface speed and duplex mode configuration for an interface, enter this command:
This example shows how to display the interface speed and duplex mode of Fast Ethernet interface 6/1:
Switch# show interface fastethernet 6/1
FastEthernet6/1 is up, line protocol is up
Hardware is Fast Ethernet Port, address is 0050.547a.dee0 (bia 0050.547a.dee0)
MTU 1500 bytes, BW 100000 Kbit, DLY 100 usec,
reliability 255/255, txload 1/255, rxload 1/255
Encapsulation ARPA, loopback not set
Keepalive set (10 sec)
Full-duplex, 100Mb/s
ARP type: ARPA, ARP Timeout 04:00:00
Last input 00:00:54, output never, output hang never
Last clearing of "show interface" counters never
Command Purpose
Step 1
Switch(config)# interface gigabitethernet1/1
Specifies the interface to be configured.
Step 2
Switch(config-if)# speed nonegotiate
Disables autonegotiation on the interface.
Command Purpose
Step 1
Switch(config)# interface fastethernet
slot/interface
Specifies the interface to be configured.
Step 2
Switch(config-if)# duplex [auto | full | half]
Sets the duplex mode of the interface.
Command Purpose
Switch# show interfaces [fastethernet |
gigabitethernet | tengigabitethernet]
slot/interface
Displays the interface speed and duplex mode
configuration.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
