Chapter 51 Configuring Control Plane Policing and Layer 2 Control Packet QoS
Configuring Control Plane Policing
• ARP policing is not supported on either the classic series supervisor engines or fixed configuration
switches. It is supported on the Catalyst 4900M and 4948E switches, Supervisor Engine 6-E, and
Supervisor Engine 6L-E (use “match protocol arp” to classify).
• Only ingress CoPP is supported. So only input keyword is supported in control-plane related CLIs.
• Use ACLs and class-maps to identify data plane and management plane traffic that are handled by
CPU.
• The only action supported in CoPP policy-map is police.
• Do not use the log keyword in the CoPP policy ACLs.
Default Configuration
CoPP is disabled by default.
Configuring CoPP for Control Plane Traffic
To configure CoPP for control plane traffic, perform this task:
The following example shows how to police CDP packets:
Switch# config terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# qos
Switch(config)# macro global apply system-cpp
Switch(config)# policy-map system-cpp-policy
Switch(config-pmap)# class system-cpp-cdp
Switch(config-pmap-c)# police 32000 1000 conform-action transmit exceed-action drop
Switch(config-pmap-c)# end
Command Purpose
Step 1
Switch# config terminal
Enters global configuration mode.
Step 2
Switch(config)# qos
(Optional) Enables QoS globally.
Step 3
Switch(config)#
macro global apply system-cpp
(Optional) Creates the system-cpp-policy policy
map and attaches it to the control plane.
Step 4
Switch(config)# policy-map
system-cpp-policy
Switch(config-pmap)# class
{system-cpp-dot1x | system-cpp-bpdu-range |
system-cpp-cdp | service | system-cpp-sstp
| system-cpp-cgmp | system-cpp-ospf |
system-cpp-igmp | system-cpp-pim |
system-cpp-all-systems-on-subnet |
system-cpp-all-routers-on-subnet |
system-cpp-ripv2 | system-cpp-hsrpv2 |
system-cpp-ip-mcast-linklocal |
system-cpp-dhcp-cs | system-cpp-dhcp-sc |
system-cpp-dhcp-ss}
Switch(config-pmap-c)# police [aggregate
name] rate burst [conform-action {drop |
transmit}] [{exceed-action {drop |
transmit}}]}
Associates actions to one or multiple
system-defined control plane traffic in the service
policy map. Repeat this step if necessary.
Step 5
Switch# show policy-map system-cpp-policy
(Optional) Verifies the configuration.
