Chapter 66 Configuring Ethernet OAM and CFM
Configuring Ethernet CFM
Switch(config-ecfm-srv)# mep mpid 34
Switch(config-ecfm-srv)# continuity-check static rmep
Switch# show ethernet cfm maintenance-points remote static
-------------------------------------------------------------------------
MPID Domain Name Lvl Type Id Mep-Up
MA Name
-------------------------------------------------------------------------
23 abc 3 Vlan 5 No
test
34 abc 3 Vlan 5 No
test
Switch# show ethernet cfm errors
--------------------------------------------------------------------------------
MPID Domain Id Mac Address Type Id
MA Name Reason Lvl Age
--------------------------------------------------------------------------------
34 abc 0000.0000.0000 Vlan 5
test RMEP missing 3 421s
23 abc 0000.0000.0000 Vlan 5
test RMEP missing 3 421s
Switch#
Configuring a Port MEP
A port MEP is a down MEP that is not associated with a VLAN and that uses untagged frames to carry
CFM messages. You configure port MEPs on two connected interfaces. Port MEPs are always configured
at a lower domain level than native VLAN MEPs.
To configure Ethernet CFM port MEPs, perform this task:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# ethernet cfm domain
domain-name level level-id
Defines a CFM domain, set the domain level, and enter
ethernet-cfm configuration mode for the domain. The
maintenance level number range is 0 to 7.
Step 3
Switch(config-ecfm)# service {ma-name |
ma-number | vpn-id} port
Defines a customer service maintenance association name
or number or VPN ID to be associated with the domain,
define a port MEP, and enter ethernet-cfm-service
configuration mode.
• ma-name—a string of no more than 100 characters that
identifies the MAID.
• ma-number—a value from 0 to 65535.
• vpn-id vpn—enter a VPN ID as the ma-name.
Step 4
Switch(config-ecfm-srv)# mep mpid identifier
Defines the static remote maintenance end point identifier
in the domain and service. The range is 1 to 8191.
Step 5
Switch(config-ecfm-srv)# continuity-check
Enables sending and receiving of continuity check
messages.
