Cisco Catalyst 4500 Series Administration Guide

21-8
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 21 Configuring Cisco IOS Auto Smartport Macros
Configuring Auto Smartport Macros
Switch(config)#!!! the next command enables auto smart ports globally
Switch(config)# macro auto global processing fallback cdp
Switch(config)#
Switch(config)# exit
Switch#
Switch# show running-config interface gigabitethernet2/7
Building configuration...
Current configuration : 284 bytes
!
switchport access vlan 10
switchport mode access
switchport voice vlan 2
switchport port-security maximum 2
switchport port-security
switchport port-security aging time 2
switchport port-security violation restrict
switchport port-security aging type inactivity
auto qos voip cisco-phone
qos trust device cisco-phone
neighbor device type phone
macro description CISCO_PHONE_EVENT
spanning-tree portfast
spanning-tree bpduguard enable
service-policy input AutoQos-VoIP-Input-Cos-Policy
service-policy output AutoQos-VoIP-Output-Policy
end
Note You can also use the macro auto device command to simplify changing the parameters for a built-in
functions for a device type.
Configuring User-Defined Event Triggers
You can configure two types of event triggers: user-defined and MAC address-based.
The following sections describe these triggers:
• 802.1X-Based Event Trigger, page 21-8
• MAC Address-Based Event Trigger, page 21-9
802.1X-Based Event Trigger
When using MAB or 802.1X authentication to trigger Auto Smartport macros, you need to create an
event trigger that corresponds to the Cisco AV pair (auto-smart-port=event trigger) sent by the
RADIUS server.
To configure an event trigger, perform this task:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# shell trigger
identifier description
Specifies the event trigger identifier and description.
The identifier should have no spaces or hyphens between words.
Step 3
Switch(config)# end
Returns to privileged EXEC mode.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
