Cisco Catalyst 4500 Series Administration Guide

21-7
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 21 Configuring Cisco IOS Auto Smartport Macros
Configuring Auto Smartport Macros
The no macro auto execute event trigger {[builtin built-in macro name [parameter=value]] |
[[parameter=value] {function contents}]} command deletes the mapping.
This example shows how to use two built-in Auto Smartport macros for connecting Cisco switches and
Cisco IP phones to the switch. This example modifies the default voice VLAN, access VLAN, and native
VLAN for the trunk interface:
Switch# configure terminal
Switch(config)# macro auto execute CISCO_PHONE_EVENT builtin CISCO_PHONE_AUTO_SMARTPORT
ACCESS_VLAN=10 VOICE_VLAN=20
Switch(config)#
Switch(config)#
Step 2
Switch(config)# macro auto execute
event trigger builtin
built-in
macro name [parameter=value]
[parameter=value]
Defines mapping from an event trigger to a built-in macro.
Specify an event trigger value:
• CISCO_PHONE_EVENT
• CISCO_SWITCH_EVENT
• CISCO_ROUTER_EVENT
• CISCO_WIRELESS_AP_EVENT
• CISCO_WIRELESS_LIGHTWEIGHT_AP_EVENT
• CISCO_DMP_EVENT
• CISCO_IPVSC_EVENT
• WORD—Apply a user-defined event trigger.
Specify a built-in macro name value:
• CISCO_PHONE_AUTO_SMARTPORT
(Optional) Specify the parameter values: $ACCESS_VLAN=(1) and
$VOICE_VLAN=(2).
• CISCO_SWITCH_AUTO_SMARTPORT
(Optional) Specify the parameter values: $NATIVE_VLAN=(1).
• CISCO_ROUTER_AUTO_SMARTPORT
(Optional) Specify the parameter values: $NATIVE_VLAN=(1).
• CISCO_AP_AUTO_SMARTPORT
(Optional) Specify the parameter values: $NATIVE_VLAN=(1).
• CISCO_LWAP_AUTO_SMARTPORT
(Optional) Specify the parameter values: $ACCESS_VLAN=(1).
• CISCO_DMP_AUTO_SMARTPORT
• CISCO_IP_CAMERA_AUTO_SMARTPORT
(Optional) parameter=value—Replace default values that begin with $.
Enter new values in the form of name value pair separated by a space:
[name1=value1 name2=value2...]. Default values are shown in
parenthesis.
Step 3
Switch(config)# end
Returns to privileged EXEC mode.
Step 4
Switch# show running-config
Verifies your entries.
Step 5
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
