Cisco Catalyst 4500 Series Administration Guide

6-27
Software Configuration Guide—Release IOS XE 3.6.0SG and IOS 15.2(2)SG
OL-30933-01
Chapter 6 Configuring the Cisco IOS In-Service Software Upgrade Process
Performing the ISSU Process
Configured Rollback Time = 45:00
Automatic Rollback Time = 38:30
Switch# issu acceptversion 2 bootflash:new_image
% Rollback timer stopped. Please issue the commitversion command.
Switch# show issu rollback-timer
Rollback Process State = Not in progress
Configured Rollback Time = 45:00
Loading New Cisco IOS Software on the New Standby Supervisor Engine
This task explains how to load new version of Cisco IOS software to the new standby supervisor engine.
Perform this task at the active supervisor engine:
This example shows how to reset and reload the current standby supervisor engine (slot 1) with the new
Cisco IOS software version. After entering the commitversion command, the standby supervisor engine
boots in the Standby Hot state.
Switch> enable
Switch# issu commitversion 1 slavebootflash:new_image
Wait till standby supervisor is reloaded with the new image. Then apply the following:
Switch# show redundancy states
00:17:12: %RF-5-RF_TERMINAL_STATE: Terminal state reached for (SSO)
my state = 13 -ACTIVE
peer state = 8 -STANDBY HOT
Mode = Duplex
Unit = Secondary
Unit ID = 2
Redundancy Mode (Operational) = Stateful Switchover
Redundancy Mode (Configured) = Stateful Switchover
Redundancy State = Stateful Switchover
Maintenance Mode = Disabled
Manual Swact = enabled
Communications = Up
client count = 39
client_notification_TMR = 240000 milliseconds
keep_alive TMR = 9000 milliseconds
keep_alive count = 0
keep_alive threshold = 18
RF debug mask = 0x0
Command or Action Purpose
Step 1
Switch> enable
Enables privileged EXEC mode.
• Enter your password if prompted.
Step 2
Switch# issu commitversion standby-slot-number
[standby-image-new]
Allows the new Cisco IOS software image to be loaded into
the standby supervisor engine.
Step 3
Switch# show redundancy [states]
Displays redundancy facility state information.
Step 4
Switch# show issu state [detail]
Displays the state of the during the ISSU process. At this
point in the ISSU process, use this command to check that
a switchover occurs to slot 2.
