Page #1401 background imageLoading...
Page #1401 background image
53-25
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 53 Configuring DHCP Snooping, IP Source Guard, and IPSG for Static Hosts
Configuring IP Source Guard for Static Hosts
Configuring IPSG for Static Hosts on a Layer 2 Access Port
You can configure IPSG for static hosts on a Layer 2 access port.
To enable IPSG for static hosts with IP filters on a Layer 2 access port, perform this task:
Command Purpose
Step 1
Switch(config)# ip device tracking
Turns on the IP host table.
Step 2
Switch(config)# ip device tracking [probe {count
count | interval interval}]
(Optional) Configures these parameters for the IP device
tracking table:
• count—Number of times that the switch sends the
ARP probe. The range is 1 to 5. The default is 3.
• interval—Number of seconds that the switch waits
for a response before resending the ARP probe. The
range is 30 to 300 seconds. The default is 30
seconds.
Step 3
Switch(config)# ip device tracking [probe {delay
interval}]
(Optional) Configures the optional probe delay
parameter for the IP device tracking table:
• interval—Number of seconds that the switch delays
sending an ARP probe, triggered by link-up and
ARP probe generation by the tracked device. The
range is 1 to 120 seconds. The default is 0 seconds.
Step 4
Switch(config)# interface fastEthernet a/b
Enters IP configuration mode.
Step 5
Switch(config-if)# switchport mode access
Configures a port as access.
Step 6
Switch(config-if)# switchport access vlan n
Configures the VLAN for this port.
Step 7
Switch(config-if)# ip device tracking maximum n
Establishes a maximum limit for the bindings on this
port.
Upper bound for the maximum is 10.
Step 8
Switch(config-if)# switchport port-security
(Optional) Activates port security for this port.
Step 9
Switch(config-if)# switchport port-security
maximum n
(Optional) Establishes a maximum number of MAC
addresses for this port.
Step 10
Switch(config-if)# ip verify source tracking
[port-security]
Activates IPSG for static hosts on this port.
Step 11
Switch(config-if)# end
Exits configuration interface mode.
Step 12
Switch# show ip verify source interface-name
Verifies the configuration.
Step 13
Switch# show ip device track all
[active | inactive] count
Verifies the configuration by displaying the IP-to-MAC
binding for a given host on the switch interface.
• all active—Displays only the active IP-to-MAC
binding entries.
• all inactive—Displays only the inactive IP-to-MAC
binding entries.
• all—Displays the active and inactive IP-to-MAC
binding entries.
