Chapter 46 Configuring 802.1X Port-Based Authentication
Configuring 802.1X Port-Based Authentication
Follow these guidelines to configure voice aware 802.1x voice security on the switch:
• You enable voice aware 802.1x security by entering the errdisable detect cause security-violation
shutdown vlan global configuration command. You disable voice aware 802.1x security by entering
the no version of this command. This command applies to all 802.1x-configured ports in the switch.
Note If you do not include the shutdown vlan keywords, the entire port is shut down when it enters the
error-disabled state.
• If you use the errdisable recovery cause security-violation global configuration command to
configure error-disabled recovery, the port is automatically re-enabled. If error-disabled recovery is
not configured for the port, you re-enable it with the shutdown and no-shutdown interface
configuration commands.
• You can re-enable individual VLANs with the clear errdisable interface interface-id vlan
[vlan-list] privileged EXEC command. If you do not specify a range, all VLANs on the port are
enabled.
To enable voice aware 802.1x security, follow these steps, beginning in privileged EXEC mode:
Switch# configure terminal
Switch(config)# errdisable detect cause security-violation shutdown vlan
Switch(config)# errdisable recovery cause security-violation
Switch(config)# errdisable recovery interval interval
Switch(config)# end
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config)# errdisable detect
cause security-violation shutdown
vlan
Shuts down any VLAN on which a security violation error occurs.
Note If the shutdown vlan keywords are not included, the entire port
enters the error-disabled state and shuts down.
Step 3
Switch(config)# errdisable recovery
cause security-violation
(Optional) Enables automatic per-VLAN error recovery.
Step 4
Switch(config)# errdisable recovery
interval interval
(Optional) Sets a recovery interval (in sec). The interval range is 30 to
86400. The default is 300 sec.
Step 5
Switch(config)# end
Enters exec mode.
Step 6
Switch# clear errdisable interface
interface-id vlan [vlan-list]
(Optional) Reenables individual VLANs that have been error disabled.
• For interface-id specify the port on which to reenable individual
VLANs.
• (Optional) For vlan-list specify a list of VLANs to be re-enabled. If
vlan-list is not specified, all VLANs are re-enabled.
Step 7
Switch(config)# interface
interface-id
Enters interface configuration mode.
Step 8
Switch(config-if)# shutdown
no-shutdown
(Optional) Re-enables an error-disabled VLAN, and clears all
error-disable indications.
Step 9
Switch(config-if)# end
Returns to privileged EXEC mode.
Step 10
Switch# show errdisable detect
Verifies your settings.
Step 11
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
