Cisco Catalyst 4500 Series Administration Guide

51-7
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 51 Configuring Control Plane Policing and Layer 2 Control Packet QoS
Configuring Control Plane Policing
The following example shows how to configure trusted hosts with source addresses 10.1.1.1 and 10.1.1.2
to forward Telnet packets to the control plane without constraint, while allowing all remaining Telnet
packets to be policed at the specific rate. This example assumes that global QoS is enabled and that the
system-cpp-policy policy map was created.
Switch# config terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# qos
Switch(config)# macro global apply system-cpp
! Allow 10.1.1.1 trusted host traffic.
Switch(config)# access-list 140 deny tcp host 10.1.1.1 any eq telnet
! Allow 10.1.1.2 trusted host traffic.
Switch(config)# access-list 140 deny tcp host 10.1.1.2 any eq telnet
! Rate limit all other Telnet traffic.
Switch(config)# access-list 140 permit tcp any any eq telnet
! Define class-map "telnet-class."
Switch(config)# class-map telnet-class
Switch(config-cmap)# match access-group 140
Switch(config-cmap)# exit
! Add the class-map "telnet-class" to "system-cpp-policy" and define the proper action
Switch(config)# policy-map system-cpp-policy
Switch(config-pmap)# class telnet-class
Switch(config-pmap-c)# police 80000 1000 conform transmit exceed drop
Switch(config-pmap-c)# exit
Switch(config-pmap)# exit
! Verify the above configuration steps
Switch# show policy-map system-cpp-policy
Policy Map system-cpp-policy
Class system-cpp-dot1x
Class system-cpp-bpdu-range
Class system-cpp-cdp
police 32000 bps 1000 byte conform-action transmit exceed-action drop
Class system-cpp-sstp
Class system-cpp-cgmp
Class system-cpp-ospf
Class system-cpp-hsrpv2
Class system-cpp-igmp
Class system-cpp-pim
Class system-cpp-all-systems-on-subnet
Step 6
Switch(config)# policy-map
system-cpp-policy
Switch(config-pmap)# class {class-map-name}
Switch(config-pmap-c)# police
[aggregate name] rate burst
[conform-action {drop | transmit}]
[{exceed-action {drop | transmit}}]
Adds the traffic classes to the CoPP policy map.
Uses the police statement to associate actions to
the traffic class.
Step 7
Switch(config)# end
Returns to privileged EXEC mode.
Step 8
Switch# show policy-map system-cpp-policy
Verifies your entries.
Command Purpose

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
