Chapter 3 Configuring the Switch for the First Time
Configuring the Switch
To configure a static route, perform this task:
This example shows how to use the ip route command to configure a static route to a workstation at IP
address 171.10.5.10 on the switch with a subnet mask and IP address 172.20.3.35 of the forwarding
router:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# ip route 171.10.5.10 255.255.255.255 172.20.3.35
Switch(config)# end
Switch#
This example shows how to use the show running-config command to confirm the configuration of the
static route:
Switch# show running-config
Building configuration...
.
<...output truncated...>
.
ip default-gateway 172.20.52.35
ip classless
ip route 171.10.5.10 255.255.255.255 172.20.3.35
no ip http server
!
line con 0
transport input none
line vty 0 4
exec-timeout 0 0
password lab
login
transport input lat pad dsipcon mop telnet rlogin udptn nasi
!
end
Switch#
This example shows how to use the ip route command to configure the static route IP address 171.20.5.3
with subnet mask and connected over VLAN 1 to a workstation on the switch:
Switch# configure terminal
Switch(config)# ip route 171.20.5.3 255.255.255.255 vlan 1
Switch(config)# end
Switch#
This example shows how to use the show running-config command to confirm the configuration of the
static route:
Switch# show running-config
Building configuration...
.
<...output truncated...>
Command Purpose
Step 1
Switch(config)# ip route dest_IP_address mask
{forwarding_IP | vlan vlan_ID}
Configures a static route to the remote network.
Step 2
Switch# show running-config
Verifies that the static route is displayed correctly.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
