Cisco Catalyst 4500 Series Administration Guide

66-40
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL-28731-01
Chapter 66 Configuring Ethernet OAM and CFM
Enabling and Configuring Ethernet OAM
Step 6
Switch(config-if)# ethernet oam link-monitor
frame-period
{threshold {high {high-frames |
none} | low {low-frames}} | window frames}
Repeat this step to configure both high and low
thresholds.
(Optional) Configures high and low thresholds for the
error-frame period that triggers an error-frame-period link
event.
• Enter threshold high high-frames to set a high
threshold in number of frames. The range is 1 to
65535. The default is none.
• Enter threshold high none to disable the high
threshold if it was set. it is the default.
• Enter threshold low low-frames to set a low threshold
in number of frames. The range is 0 to 65535. The
default is 1.
• Enter window frames to set the a polling window size
in number of frames. The range is 1 to 65535; each
value is a multiple of 10000 frames. The default is
1000.
Step 7
Switch(config-if)# ethernet oam link-monitor
frame-seconds
{threshold {high {high-frames |
none} | low {low-frames}} | window milliseconds}
Repeat this step to configure both high and low
thresholds.
(Optional) Configures high and low thresholds for the
frame-seconds error that triggers an error-frame-seconds
link event.
• Enter threshold high high-frames to set a high error
frame-seconds threshold in number of seconds. The
range is 1 to 900. The default is none.
• Enter threshold high none to disable the high
threshold if it was set. it is the default.
• Enter threshold low low-frames to set a low threshold
in number of frames. The range is 1 to 900. The default
is 1.
• Enter window frames to set the a polling window size
in number of milliseconds. The range is 100 to 9000;
each value is a multiple of 100 milliseconds. The
default is 1000.
Command Purpose
