Cisco Catalyst 4500 Series Administration Guide

66-43
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL-28731-01
Chapter 66 Configuring Ethernet OAM and CFM
Enabling and Configuring Ethernet OAM
To enable Ethernet OAM remote-failure indication actions on an interface, perform this task:
This example shows how to configure Ethernet OAM remote-failure action on the switch interface:
Switch# conf terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# int gi1/1
Switch(config-if)# ethernet oam remote-failure dying-gasp action error
Switch(config-if)# ethernet oam link-monitor high-threshold action error
Switch(config-if)# end
Switch# show running-config int gi1/1
Building configuration...
Current configuration : 353 bytes
!
interface GigabitEthernet1/1
switchport trunk encapsulation dot1q
switchport trunk allowed vlan 1,19
switchport mode trunk
ethernet oam remote-loopback supported
ethernet oam link-monitor high-threshold action error-disable-interface
ethernet oam remote-failure dying-gasp action error-disable-interface
ethernet oam
end
Switch# show ethernet oam status int gi1/1
GigabitEthernet1/1
General
-------
Admin state: enabled
Mode: active
PDU max rate: 10 packets per second
PDU min rate: 1 packet per 1 second
Link timeout: 5 seconds
High threshold action: error disable interface
Link fault action: no action
Dying gasp action: error disable interface
Critical event action: no action
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(config# interface interface-id
Defines an interface and enters interface configuration
mode.
Step 3
Switch(config-if)# ethernet oam remote-failure
[dying-gasp] action error-disable-interface
Configures the Ethernet OAM remote-failure action on the
interface. You can configure disabling the interface by
selecting dying-gasp to shut down the interface when
Ethernet OAM is disabled or the interface enters the
error-disabled state.
Step 4
Switch(config-if)# end
Returns to privileged EXEC mode.
Step 5
Switch# show ethernet oam status [interface
interface-id
]
Verifies the configuration.
Step 6
Switch# copy running-config startup-config
(Optional) Saves your entries in the configuration file.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
