Cisco Catalyst 4500 Series Administration Guide

66-46
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL-28731-01
Chapter 66 Configuring Ethernet OAM and CFM
Enabling and Configuring Ethernet OAM
Step 4
Switch(config-template)# ethernet oam
link-monitor symbol-period
{threshold {high
{high symbols | none} | low {low-symbols}} |
window symbols
}
(Optional) Configures high and low thresholds for an
error-symbol period that triggers an error-symbol period
link event.
• Enter threshold high high-symbols to set a high
threshold in number of symbols. The range is 1 to
65535.
• Enter threshold high none to disable the high
threshold.
• Enter threshold low low-symbols to set a low
threshold in number of symbols. The range is 0 to
65535. It must be lower than the high threshold.
• Enter window symbols to set the window size (in
number of symbols) of the polling period. The range is
1 to 65535 symbols.
Step 5
Switch(config-template)# ethernet oam
link-monitor frame
{threshold {high
{high-frames | none} | low {low-frames}} | window
milliseconds
}
(Optional) Configures high and low thresholds for error
frames that trigger an error-frame link event.
• Enter threshold high high-frames to set a high
threshold in number of frames. The range is 1 to
65535. You must enter a high threshold.
• Enter threshold high none to disable the high
threshold.
• Enter threshold low low-frames to set a low threshold
in number of frames. The range is 0 to 65535. The
default is 1.
• Enter window milliseconds to set the a window and
period of time during which error frames are counted.
The range is 10 to 600 and represents the number of
milliseconds in a multiple of 100. The default is 100.
Step 6
Switch(config-template)# ethernet oam
link-monitor frame-period
{threshold {high
{high-frames | none} | low {low-frames}} | window
frames
}
(Optional) Configures high and low thresholds for the
error-frame period that triggers an error-frame-period link
event.
• Enter threshold high high-frames to set a high
threshold in number of frames. The range is 1 to
65535. You must enter a high threshold.
• Enter threshold high none to disable the high
threshold.
• Enter threshold low low-frames to set a low threshold
in number of frames. The range is 0 to 65535. The
default is 1.
• Enter window frames to set the a polling window size
in number of frames. The range is 1 to 65535; each
value is a multiple of 10000 frames. The default is
1000.
Command Purpose
