Cisco Catalyst 4500 Series Administration Guide

23-7
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)E
OL_28731-01
Chapter 23 Configuring Flex Links and MAC Address-Table Move Update
Configuring Flex Links
To disable a Flex Links backup interface, enter the no switchport backup interface interface-id
interface configuration command.
This example shows how to configure an interface with a backup interface and to verify the
configuration:
Switch# configure terminal
Switch(conf)# interface fastethernet1/1
Switch(conf-if)# switchport backup interface fastethernet1/2
Switch(conf-if)# end
Switch# show interface switchport backup
Switch Backup Interface Pairs:
Active Interface Backup Interface State
------------------------------------------------------------------------
FastEthernet1/1 FastEthernet1/2 Active Up/Backup Standby
FastEthernet1/3 FastEthernet1/4 Active Up/Backup Standby
Port-channel1 GigabitEthernet1/1 Active Up/Backup Standby
To configure a preemption scheme for a pair of Flex Links, perform this task:
Command Purpose
Step 1
Switch# configure terminal
Enters global configuration mode.
Step 2
Switch(conf)# interface interface-id
Specifies the interface, and enters interface configuration
mode. The interface might be a physical Layer 2 interface
or a port channel (logical interface). The port channel
range is 1 to 64.
Step 3
Switch(conf-if)# switchport backup interface
interface-id
Configures a physical Layer 2 interface (or port channel)
as part of a Flex Links pair with the interface. When one
link is forwarding traffic, the other interface is in standby
mode.
Step 4
Switch(conf-if)# switchport backup interface
interface-id preemption mode [forced | bandwidth
| off]
Configures a preemption mechanism and delay for a Flex
Links interface pair. You can configure the preemption
mode as:
• forced—The active interface always preempts the
backup.
• bandwidth—The interface with higher bandwidth
always acts as the active interface.
• off—No preemption occurs from active to backup.
Step 5
Switch(conf-if)# switchport backup interface
interface-id preemption delay delay-time
Configures the delay time until a port preempts another
port.
Note Setting a delay time requires forced or bandwidth
mode.
Step 6
Switch(conf)# end
Returns to privileged EXEC mode.
Step 7
Switch# show interface [interface-id] switchport
backup
Verifies the configuration.
Step 8
Switch# copy running-config startup config
(Optional) Saves your entries in the switch startup
configuration file.
