Cisco Catalyst 4500 Series Administration Guide

39-14
Software Configuration Guide—Release IOS XE 3.6.0E and IOS 15.2(2)SG
OL_28731-01
Chapter 39 Configuring Bidirection Forwarding Detection
How to Configure Bidirectional Forwarding Detection
To configure BFD support for static routing, perform this task:
Command or Action Purpose
Step 1
enable
Switch> enable
Enables privileged EXEC mode.
• Enter your password if prompted.
Step 2
configure terminal
Switch# configure terminal
Enters global configuration mode.
Step 3
interface type number
Switch(config)# interface gigabitethernet6/1
Configures an interface and enters interface configuration
mode.
Step 4
no switchport
Switch(config-if)# no switchport
Changes the interface to Layer 3.
Step 5
ip address ip-address mask
Switch(config-if)# ip address 10.201.201.1
255.255.255.0
Configures an IP address for the interface.
Step 6
bfd interval milliseconds min_rx milliseconds
multiplier interval-multiplier
Switch(config-if)# bfd interval 500 min_rx 500
multiplier 5
Enables BFD on the interface.
Step 7
exit
Switch(config-if)# exit
Exits interface configuration mode and returns to global
configuration mode.
Step 8
ip route static bfd interface-type
interface-number ip-address [group group-name
[passive]]
Switch(config)# ip route static bfd
Gi6/1 10.1.1.1 group group1 passive
Specifies a static route BFD neighbor.
• The interface-type, interface-number, and ip-address
arguments are required because BFD support exists
only for directly connected neighbors.
Step 9
ip route [vrf vrf-name] prefix mask {ip-address
| interface-type interface-number [ip-address]}
[dhcp] [distance] [name next-hop-name]
[permanent | track number] [tag tag]
Example:
Switch(config)# ip route 10.0.0.0 255.0.0.0
Gi6/1 10.201.201.2
Specifies a static route BFD neighbor.
Step 10
exit
Example:
Switch(config)# exit
Exits global configuration mode and returns to privileged
EXEC mode.
Step 11
show ip static route
Example:
Switch# show ip static route
(Optional) Displays static route database information.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
