CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–39 MN-CDM570A
(CONFIG: TI) G703  T1
T1 Configuration: Length
Line-Code (◄ ►,ENTER)
Use the
◄ ► arrow keys to select Length or Line Code. Press ENTER.
(CONFIG: TI) G.703: T1  Length
T1 Line Length:
000-133 feet (▲ ▼,ENTER)
The valid length spans, in feet, are 0-133, 133-266, 266-399, 399-533, or 533-655.
Use the ▲▼arrow keys to select the desired span. Press ENTER.
(CONFIG: TI) G.703: T1  Line-Code
T1 Line Code (B8ZS):
On Off(AMI) (◄ ►,ENTER)
Use the
◄ ► arrow keys to select On or Off. Press ENTER.
(CONFIG: TI) G.703  E1-Bal or E1-Unbal
E1 Line Code (HDB3):
On Off (◄ ►,ENTER)
When you select E1-Bal or E1-Unbal, the modem displays this typical submenu.
Use the
◄ ► arrow keys to set operation as On or Off. Press ENTER.
6.3.2.7.4 IP-ACM (VersaFEC ACM)
This selection is functional only when the optional Packet Processor is installed.
ACM:ModCod Unlock-Action
Target-SNR-Margin
Use the
◄ ► arrow keys to select a parameter. Press ENTER.
(CONFIG: TI) IP-ACM  ModCod
Min ModCod:00 16QAM .488
Max ModCod:11 16QAM .853
