CDM-570L/570AL Satellite Modem with Optional Packet Processor
Revision 5
Optional High Performance Packet Processor D–29 MN-CDM570A
D.2.6.3 Set IP Address(es)
Do these steps (the applicable CLI “hot key” is shown in brackets [#]):
Step
Task
1
From the CLI Main Menu:
Select the Interface Configuration submenu [I].
2
From the Interface Configuration Menu:
Select Ethernet Interface submenu [E].
3
Set Ethernet IP Address [I].
• CDM-IP 1 to 172.17.10.1
• CDM-IP 2 to 172.16.10.1
4
Set the Ethernet Subnet Prefix Length [M] to 24.
D.2.6.4 Set Route Table Entries
First, do these steps on CDM-IP 1 (the applicable CLI “hot key” is shown in brackets [#]):
Step
Task
1
From the CLI Main Menu:
Select the Route Table [R] submenu.
2
Enter 1 to configure the first route.
3
Enter a suitable name.
4
Set IP Address to 172.16.10.0
5
Set Number of Subnet Bits to 24.
6
For Interface to which route is destined to <E-Ethernet S-Satellite Enter : S> select S.
7
The CDM-IP 1 Route Table should display the following:
Route Name Dest IP/SNet Bits Next Hop MultiCast State
Route001...[test 172.16.10.0/24 POINT-TO-POINT N/A toSat]
